CCTV Power Adaptor 12V 2A Desktop DC Adapter 5.5*2.1mm 2.5mm AC DC Power Adapter with EU US UK Plug

Shenzhen Kuncan Electronics Co., Ltd.
Manufacturer, Trading Company (Gold Supplier)
Shop Opened    7 Years
Star Level:0
Product Price : USD 3.00~3.60
Min Order : 500 Pieces

Place of Origin: Guangdong, China
Brand Name: KUNCAN
Model Number: KC-S9209
Usage: Laptop ,Mobile Phone
Connection: Desktop
Output Type: AC/DC
Type: DC/AC 12v 2a laptop power adpater desktop power supply
Output: 12V 2A 8A 7A 6A 5A 4A
DC Plug: DC5.5*2.5mm DC5.5*2.1mm
Cable length: 1.5m or customize
Certification: CE,FCC,ROHS
Waranty: 2 years
Colour: black
Input Connector: IEC C13 , C5,C7
Weight: 0.25-0.3kg
OEM: Accept

CCTV Power Adaptor 12V 2A Desktop DC Adapter 5.5*2.1mm 2.5mm AC DC Power Adapter with EU US UK Plug

Product Description





InputInput voltageAC 100~240V
Variation Frequency47~63Hz
Input frequence50~60Hz
OutputOutput voltage24V
Output current2A 2.5A etc optional
Output power48W or optional
Input plug typesIEC C13 to C14
Out plug typesDC jack, etc.
DC jack size5.5*2.1mm, 5.5*2.5mm, 3.5*1.35mm, 3.5*1.0mm, 4.0*1.7mm, 2.5*0.7mm .etc
AC PLUG TYPE

AU,UK,Eu Plug

Safety protectionOver voltage protection120% min
Over current protection120% min
Short circuit protectionauto recovery
Over hot protectionauto recovery
Electronic characteristicsOperating Temperature-40~50°C
Storage Temperature-40 to +85 °C
Humidity10%~95%RH
Efficiency80%
Ripple And NoiseOutput voltage 1%, Ripple&Noise≤120mv
Turn-on Delay Time3 second max
Overshoot at Turn-on10% max when turn on or off
AC leakage Current0.25mA max at AC 240V voltage
Load Regulation±5%
Line Regulation±5%
High-Voltage testPrimary to secondary: 3 kV / 5mA 60S
Drop Test0.75m drop test, 6 times
Burn-In Test100% load, 5hours
ApplicationCD/DVD,MP3/MP4,Digital camera,Comunication Terminals Etc
Safe CertificateCE ROHS FCC USAVDE CE BS SAA C-tick PSE

Click here for more information

Packaging & Shipping



Packing Terms

1.Unit Weight:Range from 70g~200g according to normal length 0.5m~3m

2.Unit Packing: Tied, then bulk packing or Plastic bag packing

3.Carton Size: 40*40*27cm, 15.5*15.5*10.5 inch

4.QTY/CTN:100~200PCS

5. G.W./CTN:11KG~18KG

6. Carton Materials:ROHS approval

  Shipping Terms

1.Main Exporting Area:European, North American,Turkey,South Koea, North Asia

2.Price Terms:EXW,FOB,CIF,FCA,DDU

3.Shipping Way:By air, By train, By sea or combined shipment.

4.Express Way:FedEx,DHL,TNT,UPS,EMS,SF etc.

5.Acceptable Payment Terms:WestUnion, L/C at sight, L/C against B/L, T/T.

6.Payment:30% deposit,Balance before shippment or against B/L copy.

7.Lead Time:7-15 days according to order quantity after all details are confirmed
